Ateljé Lyktan Quad

Image 1 of 3

Ateljé Lyktan

Ateljé Lyktan Quad

”The idea was to make a downlight that isn’t just a hole in the ceiling”, says Kristian Andréason of Andréason and Leibel about Quad — the studio’s LED light for ateljé Lyktan. “Normally downlights don’t do much for the experience of a space, but we wanted to make an impact with this light”.

Manufacturer
Ateljé Lyktan
Luminaire type
Recessed luminaires

from 516 €

VAT included. We'll put together the exact price for the version you choose in your quote.

On the manufacturer site

Technical data, dimensioned drawings and files are on the manufacturer’s own page, where the latest version always lives.

Features

  • Installation: The latest generation of Quad is equipped with simple mounting springs for installation without tools.
  • Diffuser: Choose between deglaring prisma in acrylic glass with precise light control or opal acrylic glass for wider beam.

Applications

  • Office & education
  • Healthcare

Technical data

  • CRI: 80 / 90
  • CCT: 3000K / 4000K
  • Efficiency: 70-105 lumen/W
  • Lifetime LED: L100B10 60 000h
  • Material: Body in white laquered steel.
  • Light source: Quad: LED light source, colour temperature 3000K or 4000K.
  • Driver: DSI/DALI driver with light regulation 1-100% and CLO.
  • Diffuser: Opal acrylic glass or microprismatic acrylic glass in combination with optical film from BrightView.
  • Weight: Quad 260 1,6 kg.
  • Luminous flux: 1150–3850 lm
  • Power: 15–39 W

Protection and resistance

  • IP20
